Product Summary

The MPX5700 series piezoresistive transducer is a state–of–the–art monolithic silicon pressure sensor designed for a wide range of applications, but particularly those employing a microcontroller or microprocessor with A/D inputs.

Parametrics

Absolute maximum ratings: (1)Overpressure (P2 ≤ 1 Atmosphere): 2800 kPa; (2)Burst Pressure (P2 ≤ 1 Atmosphere): 5000 kPa; (3)Storage Temperature: –40 to +125 ℃; (4)Operating Temperature: –40 to +125 ℃.

Features

Features: (1)2.5% Maximum Error over 0℃ to 85℃; (2)Ideally Suited for Microprocessor or Microcontroller-Based Systems; (3)Available in Differential and Gauge Configurations; (4)Patented Silicon Shear Stress Strain Gauge; (5)Durable Epoxy Unibody Element.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MPX5700AP
MPX5700AP

Freescale Semiconductor

Board Mount Pressure / Force Sensors INTEGRATED PRESSURE SENSR

Data Sheet

0-1: $8.56
1-25: $7.74
25-50: $6.62
50-100: $5.36
