Product Summary

The EP3C40F780C8N is a Cyclone III Device.

Parametrics

EP3C40F780C8N absolute maximum ratings: (1)VCCINT Supply voltage for internal logic: –0.5 to 1.8 V; (2)VCCIO Supply voltage for output buffers: –0.5 to 3.9 V; (3)VCCA Supply voltage (analog)for phase-locked loop (PLL)regulator: –0.5 to 3.75 V; (4)VCCD_PLL Supply voltage (digital)for PLL: –0.5 to 1.8 V; (5)VI DC input voltage: –0.5 to 3.95 V; (6)IOUT DC output current, per pin: –25 to 40 mA; (7)VESDHBM Electrostatic discharge voltage using the human body model: ±2000 V; (8)VESDCDM Electrostatic discharge voltage using the charged device model: ±500 V; (9)TSTG Storage temperature: –65 to 150 ℃; (10)TJ Operating junction temperature: –40 to 125 ℃.

Features

EP3C40F780C8N features: (1)II Input pin leakage current VI = 0 V to VCCIOMAX: –10 to 10 μA; (2)IOZ Tristated I/O pin leakage current VO = 0 V to VCCIOMAX: –10 to 10 μA.

Diagrams

EP3C40F780C8N pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EP3C40F780C8N
EP3C40F780C8N


IC CYCLONE III FPGA 40K 780FBGA

Data Sheet

0-1: $66.60
